HTI DALI 315 DIM

GTIN: 4008321957344 Folding box / 1 Show all packages

Contact sales

DALI trailing-edge phase dimmer
Dimming of high voltage halogen and incandescent lamps
Dimming of many common dimmable line voltage LED lamps
Dimming of electronic transformers
Standby power consumption: < 0.5 W
DALI/Touch DIM control signal
Short-circuit protection, overload protection, overtemperature protection: electronically reversible
RI suppression: to EN 55015 (A1: 2007)
Line harmonics according to EN 61000-3-2
Safety: to EN 61347
Immunity according to EN 61547
Device fits also for special applications where dimming below 1 % is required

Length	153.00 mm
Mounting hole spacing, length	146,0 mm
Width	54.00 mm
Height	36.00 mm
Product weight	137.00 g

Ambient temperature range	0…+45 °C
Max.housing temperature in case of fault	110 °C
Permitted rel. humidity during operation	5…85 % ¹⁾

¹⁾ Maximum 56 days/year at 85 %

Encapsulated

Dimmable	Yes
Dimming interface	Phase cut-off
Dimming range	0.1…100 % ¹⁾
Overheating protection	Automatic reversible
Max. cable length to lamp/LED module	100 m
Type of connection, output side	Screw connection

¹⁾ Depends on the lamp type (please see www.osram.com/dim)

Protection class	II
Type of protection	IP20

Temperature range at storage

-40…+85 °C

Quantity of precious metals	0 mg
Quantity of rare earths	0 mg
Minimum rate of recycled material in packaging	80 % ¹⁾
Minimum percentage of recycled content in the product	0 % ¹⁾
Product recyclability	Mostly recyclable product ¹⁾
Packaging recyclability	Mostly recyclable packaging ¹⁾
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage	No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage	No
