SYLVANIA ValueLED™ HID Replacement High Lumen A-Line Lamps

HIDr High Lumen A21 17W UNV 5000K MED

Download data sheet
Contact sales
Our warranty conditions

PRODUCT DETAILS

Areas of application
  • Indoor low bay
  • Bollards
  • Post tops
Product features
  • Rated for open and enclosed fixtures
  • No warm-up time, instant-on with full light output and stable color
  • 360° beam angle (or omnidirectional) with Type V distribution
  • Up to 135 LPW
  • Passive cooling design (higher reliability with no internal fan)
  • 80 CRI, R9>0
  • Energy savings up to 84 %
  • Available in 120-277V
  • 2KV surge
  • Easy to install, UL type B requires easy ballast bypass
Safety advice
  • Verify fixture size before installation to ensure fit.
  • Not for use with dimmers.
  • Should not be directly exposed to water.
  • Please read and comply with all instructions, including the installation manual included inside the packaging before attempting installation.
  • All installation, inspection, and maintenance of lighting fixtures should be done with the power to the fixture turned off.
  • Lamps should be installed and operated in compliance with the National Electrical Code (NEC), Underwriters Laboratories Inc. (UL) requirements, and all applicable codes and regulations.
  • See installation manual for wiring options.
  • Ensure lamp holders/sockets are in good operating condition before installation and if any defects are detected, change the lamp holders/sockets.
  • Do not make or alter any open holes in an enclosure of wiring or electrical components during installation.
Electrical data
Nominal wattage 17 W
Construction wattage 17.00 W
Nominal voltage 120 V
Claimed equiv. conventional lamp power 100 W
Photometrical data
Luminous flux 2100 lm
Luminous efficacy 123 lm/W
Color temperature 5000 K
Color rendering index Ra 80
Light color 850
Dimensions & Weight
Overall length 134.00 mm
Diameter 67.00 mm
Product weight 195.00 g
Additional product data
Base (standard designation) E26
Capabilities
Dimmable No
Country-specific categorizations
Order reference 17W/850 120V 6X
Energy labelling regulation data acc EU 2019/2015
Light source cap-type (or other electric interface) E26
Length 134.00 mm
Height 67.00 mm
Width 67.00 mm
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4058118200368 Folding box
1
4058118191710 Shipping box
6		 224 mm x 154 mm x 165 mm 1610.00 g 5.69 dm³
Product information bulletin
LED562 SYLVANIA Lamps ValueLED High Lumen A-Line Lamp
PDF (449.34 KB)
Other documents / promotion
LED Lamp Contractor Series Limited Product Warranty
PDF (256.34 KB)
Product image: white background, upright
Bollard Retrofit 17W
JPG (1.49 MB)
IES files (IES, additional)
HIDr IES LM79
ZIP (14.5 MB)
