PL PROT 625 ZB P 36W 830

NEW

GTIN: 4099854514630 Folding box / 1 Show all packages

Tools

Suitable luminaire for DIRECT EASY / VIVARES Zigbee and other Zigbee 3.0 Light Management Systems
Suitable for use in applications where a higher IP protection is needed
High lumen output with up to 5040 lm
Tool-free electrical connection due to push button connector
Through-wiring possible with included connector box
Energy savings thanks to high system efficacy: up to 140 lm/W
High color consistency with SDCM 3
Extended services such as energy monitoring and remote maintenance possible with Zigbee versions
External driver for extended flexibility and easy installation
Easy cleanable frontside thanks to the smooth PMMA surface of the diffuser

IoT-ready luminaire with Zigbee 3.0 technology
Type of protection: IP54 (frontside), IP20 (backside)
Steel housing with notch in the backside for the driver to allow maximum height of 34 mm
PMMA diffuser
5-pole terminal block, cable cross section up to 5 x 2.5 mm²
Lifetime (L90/B10): 50,000 h (at 25° C)
Panel can be customized with optical sensors on individual request

Accessories for several mounting options available
Connector box with 5-pole terminal included
Security brackets preinstalled
External control gear included
Special mounting frame with an overall height of only 50 mm available separately

Nominal wattage	36.00 W
Nominal voltage	220…240 V
Mains frequency	0/50/60 Hz
Nominal current	165.000 mA
Inrush current	60 A
Inrush current time T_h50	2.72 µs
Max. number of luminaires per miniature circuit breaker B16	12
Max. number of luminaires per miniature circuit breaker C10	10
Max. number of luminaires per miniature circuit breaker C16	16
Power factor λ	> 0.90
Total harmonic distortion	< 20 %
Protection class	II
Surge capability (L-N)	1000 V
Operating mode	External LED driver

Luminous flux	5040 lm
Total luminous flux of contained light sources	6000 lm
Luminous efficacy	140 lm/W
Color temperature	3000 K
Light color (designation)	Warm White
Color rendering index Ra	> 80
Standard deviation of color matching	3 sdcm
Low flicker	Yes
Flickering metric (Pst LM)	< 1
Stroboscope effect metric (SVM)	< 0.4
Photobiological safety group acc. to EN62778	RG0
Beam angle	120 °
UGR	< 22

Product color	White
Housing color	White
Body material	Steel
Cover material	Polymethylmethacrylate (PMMA)
Light emitting surface material	Polymethylmethacrylate (PMMA)
Glow Wire Test according to IEC 60695-2-12	650 °C
Mercury content	0.0 mg

Ambient temperature range	-10…+50 °C
Temperature range at storage	-20…+70 °C
Type of connection	Screwless terminal, 3-POLE (L, N, PE)
Type of protection	IP54/IP20
Protection class IK (shock resistance)	IK02
Dimmable	Yes
IoT ready	Support of Zigbee Data Clusters: 0x0302 (Luminaire Asset Management), 0x0702 (Smart Energy: Metering), 0x0B04 (Electrical Measurement) ¹⁾
Mounting type	Recessed/Suspended/Surface
Mounting location	Ceiling
Application environment	Indoor
Mounting length	600 mm
Mounting width	600 mm
Mounting depth	50 mm
Adjustable	No
With light source	Yes
Replaceable light source	Yes

¹⁾ Internet of Things. Supports data transfer via gateway to cloud-based monitoring platforms, such as LEDVANCE VIVARES Cloud

¹⁾ t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)

Type of Emergency Lighting (EL)	EL certified driver (0Hz / DC operation) for central battery operation included
Type of emergency operation test	None
Wattage in emergency operation mode	6.5 W
Luminous flux in emergency operation mode	720 lm

Standards	CE, CB, TÜV, UKCA, EL
Luminaire with limited surface temperature, "D sign"	No
Ball shot safe	No
Replaceable light source (EPREL)	Not replaceable

Product remark	Available from September 2025
Added function	VIVARES

Minimum rate of recycled material in packaging	80 % ¹⁾
Minimum percentage of recycled content in the product	0 % ¹⁾
Product recyclability	Mostly recyclable product ¹⁾
Packaging recyclability	Mostly recyclable packaging ¹⁾
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage	No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage	Yes
List of substances of very high concern in concentrations greater than 0.1% in mass percentage	Lead (7439-92-1)

¹⁾ According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product code	Packaging unit (Pieces/Unit)	Dimensions (length x width x height)	Gross weight	Volume
4099854514630	Folding box 1	41 mm x 627 mm x 627 mm	2628.00 g	16.12 dm³
4099854514647	Shipping box 5	645 mm x 229 mm x 656 mm	14238.00 g	96.89 dm³

Product name	Product brand	Product component type	GTIN
MANUAL CONTROL UNIT SELECT DIRECT 100-240 TW RGB ZB	LEDVANCE	Light control	4099854476334
SENSOR DIRECT LS-PD-7 IR CI ZB	LEDVANCE	Light control	4099854476358
SWITCH KINETIC DIRECT 4B WT M ZB	LEDVANCE	Light control	4099854589799
SWITCH KINETIC DIRECT 4B WT G ZB	LEDVANCE	Light control	4099854589812
SWITCH KINETIC DIRECT 4B BK ZB	LEDVANCE	Light control	4099854589836
SWITCH KINETIC DIRECT 4B GR ZB	LEDVANCE	Light control	4099854589850
VIVARES ZB CONTROL	LEDVANCE	Light control	4058075427488
VIVARES ZB L/O SENS 220-240	LEDVANCE	Light control	4058075446182
VIVARES ZB O SENS 220-240	LEDVANCE	Light control	4058075544222
VIVARES ZB COUPLER	LEDVANCE	Light control	4058075463806
VIVARES ZB SENS ADAPTER	LEDVANCE	Light control	4058075650107
