PANEL VALUE 600 UGR < 19
PANEL VAL 600 UGR < 19 36 W 3000 K WT
GTIN: 4058075392427
Folding box / 1
Show all packages
5-year warranty
PRODUCT DETAILS
Product benefits
- Value for money luminaire
- Good glare reduction (UGR < 19)
- Low flicker light thanks to special electronic control gear
- Energy savings thanks to system efficacy of up to 100 lm/W
- External driver for extended flexibility and easy installation
- Versions with DALI ECG available
Areas of application
- Direct replacement for luminaires with fluorescent lamps
- Offices, conference rooms
- Reception areas, foyers, corridors, elevators
- Suitable for recessed ceiling systems with grid size of 600 x 600 mm
Product features
- Lifetime (L70/B50) up to 50,000 h (at 25 °C)
- Extruded aluminum frame
- Polystyrene diffuser
Equipment / Accessories
- Accessories for several mounting options available
- External control gear included
- Security brackets included
Safety advice
- All electrical connections must be made by a qualified person.
- Caution, risk of electric shock.
- The luminaires are not suitable for covering with thermally insulated material.
References / Links
- For Guarantee see www.ledvance.com/guarantee
Electrical data
| Nominal wattage | 36.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 170 mA |
| Inrush current | 10.4 A |
| Inrush current time Th50 | 200 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 19 |
| Max. number of luminaires per miniature circuit breaker C10 | 19 |
| Max. number of luminaires per miniature circuit breaker C16 | 30 |
| Power factor λ | > 0.90 |
| Total harmonic distortion | < 15 % |
| Protection class | II |
| Operating mode | External LED driver |
Photometrical data
| Luminous flux | 3600 lm |
| Luminous efficacy | 100 lm/W |
| Color temperature | 3000 K |
| Light color (designation) | Cool White |
| Color rendering index Ra | > 80 |
| Standard deviation of color matching | 5 sdcm |
| Luminous intensity | - |
| Low flicker | Yes |
| Flickering metric (Pst LM) | - |
| Stroboscope effect metric (SVM) | - |
| Photobiological safety group acc. to EN62778 | RG0 |
| Beam angle | 90 ° |
| UGR | < 19 |
Dimensions & Weight
| Length | 595.00 mm |
| Height | 35.00 mm |
| Width | 595.00 mm |
| Product weight | 1800.00 g |
Materials & Colors
| Product color | White |
| Housing color | White |
| Body material | Steel |
| Cover material | Polystyrene (PS) |
| Light emitting surface material | Polystyrene |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
Application & Mounting
| Ambient temperature range | -10…+45 °C |
| Type of connection | Screwless terminal |
| Type of protection | IP40 |
| Protection class IK (shock resistance) | IK02 |
| Dimmable | No |
| Mounting type | Recessed/Suspended/Surface |
| Mounting location | Ceiling, Wall |
| Application environment | Indoor |
| Mounting length | 580 mm |
| Mounting width | 580 mm |
| Mounting depth | 50,0 mm |
Lifespan
| Lifespan L70/B50 at 25 °C | 50000 h 1) |
| Lifespan L80/B10 at 25 °C | 50000 h 1) |
| Lifespan L90/B10 at 25 °C | 30000 h |
| Number of switching cycles | 25000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
Control gear
| ECG - Output ripple current | ≤ 5 % |
Certificates & Standards
| Standards | CE, CB, EAC |
| Luminaire with limited surface temperature, "D sign" | No |
| Ball shot safe | No |
| Replaceable light source (EPREL) | Not replaceable |
PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Additional info can be provided per individual request |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075392427 | Folding box 1 |
602 mm x 40 mm x 648 mm | 2192.00 g | 15.60 dm³ |
| 4058075392434 | Shipping box 4 |
667 mm x 182 mm x 634 mm | 10015.00 g | 76.96 dm³ |
User instruction / safety instructions
PL VAL UI
PL VAL UI
User instruction / safety instructions
PL VAL 600 625
PL VAL 600 625
Legal information
LSI PL VAL AND PL VAL DALI
LSI PL VAL AND PL VAL DALI
Legal information
LSI PL VAL AND PL VAL DALI
LSI PL VAL AND PL VAL DALI
Declarations of conformity
PL VAL
PL VAL
Product image: white background, diagonal
PANEL
PANEL
Product image: white background, horizontal
PANEL
PANEL
Product line drawing with letters
PL VAL 600 36W TPB
PL VAL 600 36W TPB
Product line drawing with numbers
PL VAL 600 36W TPB
PL VAL 600 36W TPB
Product line drawing, front, no dimensions
PL VAL 600 36W TPB
PL VAL 600 36W TPB
Packaging image, spacial
Panel VAL 600 UGR19 white 36W 830 MiCh
Panel VAL 600 UGR19 white 36W 830 MiCh
Catalog info 1
Panel LED Value 600
Panel LED Value 600
Catalog info 2
Panel LED Value 600
Panel LED Value 600
Catalog info 5
Panel LED Value 600
Panel LED Value 600
IES file (IES)
PL VAL 600 36W 3000K UGR19
PL VAL 600 36W 3000K UGR19
LDT file (Eulumdat)
PL VAL 600 36W3000K UGR19
PL VAL 600 36W3000K UGR19
ROLF file (RELUX)
PL VAL 600
PL VAL 600
UGR file (UGR table)
PL VAL 600 36W 3000K UGR19
PL VAL 600 36W 3000K UGR19
Light distribution curve type cone
PL VAL 600 36W 3000K UGR19
PL VAL 600 36W 3000K UGR19
Light distribution curve type polar
PL VAL 600 36W 3000K UGR19
PL VAL 600 36W 3000K UGR19
Tender documents
PANEL VALUE 600 UGR 19 36 W 3000 K WT-EN
PANEL VALUE 600 UGR 19 36 W 3000 K WT-EN
| EAN | SEG number | STK number | EFO number | ELDAS number |
|---|---|---|---|---|
| 4058075392427 | 7018121 | 4283683 | 3000476 | 941402450 |
