HCI-TT 70 W/830 SUPER 4Y

Phase out

GTIN: 4052899378339 Sleeve / 1 Show all packages

Contact sales

Up to 15 % higher lumen maintenance factor compared to HCI-TT standard lamps
Up to 30 % higher lum. efficacy for lamps ≤ 100 W (comp. to NAV-T Super 4Y/6Y)
Good color rendering
Operation in existing HPS installations as ignition voltage of IEC 60662 is met
Energy savings of up to 70 % when replacing mercury vapor lamps (HQL)
Optimum energy efficiency on POWERTRONIC® PTo 3DIM ECGs
UV values significantly below the maximum permitted thresholds to IEC 61167 thanks to UV filter

Where possible, use a timer igniter (switch-off time of at least 15 minutes). Otherwise, switch off the luminaire for at least 15 minutes if a brief interruption has occurred to the mains voltage supply.
Disconnect mains before installation.
Must not be used if outer bulb is defective.
Do not stare at the operating light source: The luminaire should be positioned so that prolonged staring into the luminaire at a distance closer that 4 m is not expected.
Lamp to be used only in a closed luminaire.

For more information on the system guarantee and the terms and conditions of the guarantee visit www.ledvance.com/system-guarantee

Nominal wattage	70 W
Construction wattage	77.00 W
Nominal voltage	95 V
Ignition voltage	1.8/5.0 kVp ¹⁾
Operating mode	Conventional control gear (CCG) and ignitor, Electronic control gear (ECG)
Nominal current	1 A
PFC capacitor at 50 Hz	12 µF

¹⁾ Minimum / Maximum

Luminous flux	8000 lm
Luminous efficacy	107 lm/W
Color temperature	3200 K
Color rendering index Ra	80
Light color	832
Rated LLMF at 2,000 h	0.92
Rated LLMF at 4,000 h	0.90
Rated LLMF at 6,000 h	0.89
Rated LLMF at 8,000 h	0.88
Rated LLMF at 12,000 h	0.85
Rated LLMF at 16,000 h	0.83
Rated LLMF at 20,000 h	0.75
Rated lamp efficacy (standard co.)	104 lm/W
UV protection	Yes

Maximum permitted outer bulb temperature	350 °C
Maximum permitted base edge temperature	210 °C

Rated lamp survival factor at 2,000 h	0.99
Rated lamp survival factor at 4,000 h	0.99
Rated lamp survival factor at 6,000 h	0.98
Rated lamp survival factor at 8,000 h	0.97
Rated lamp survival factor at 12,000 h	0.97
Rated lamp survival factor at 16,000	0.95
Rated lamp survival factor at 20,000 h	0.78
Lifespan B10	18000 h
Lifespan B5	16000 h
Lifespan B50	24000 h
Operation mode LLMF/LSF	50 Hz

Dimmable	Yes ¹⁾
Burning position	Any
Enclosed luminaire required	Yes

¹⁾ In combination with POWERTRONIC PTo

Energy efficiency class	F
Energy consumption	84.70 kWh/1000h

ILCOS	MT/UB-70/830-H/E/SL-E27-32/155
Order reference	HCI-TT 70W/830

Lighting technology used	MH
Non-directional or directional	NDLS
Mains or non-mains	NMLS
Light source cap-type (or other electric interface)	E27
Connected light source (CLS)	No
Color-tuneable light source	No
Envelope	SECOND
High luminance light source	No
Anti-glare shield	No
Correlated colour temperature type	SINGLE_VALUE
Claim of equivalent power	No
Length	156.00 mm
Height	35.00 mm
Width	35.00 mm
Chromaticity coordinate x	0.420
Chromaticity coordinate y	0.394
Beam angle correspondence	SPHERE_360
EPREL ID	1535148
Model number	AC01721

Quantity of precious metals	0 mg
Quantity of rare earths	0 mg
Minimum rate of recycled material in packaging	80 % ¹⁾
Minimum percentage of recycled content in the product	0 % ¹⁾
Product recyclability	Mostly recyclable product ¹⁾
Packaging recyclability	Mostly recyclable packaging ¹⁾
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage	No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage	Additional info can be provided per individual request
List of substances of very high concern in concentrations greater than 0.1% in mass percentage
