DAMP PROOF HOUSING ACCESSORIES
DP HOUSING 1500 1xLAMP TH-KIT 5x2.5
GTIN: 4058075695092
BAG / 1
Show all packages
Our warranty conditions
PRODUCT DETAILS
Product benefits
- Easy installation and electrical connection thanks to tool-free electrical connectors
Areas of application
- Parking lots, warehouses, production areas
Product features
- Through-wiring kits with tool-free connectors
Equipment / Accessories
- 5x2.5 mm² cables with tool-free connectors, cable gland and cable holders
- All required accessories included
References / Links
- For Guarantee see www.ledvance.com/guarantee
Dimensions & Weight
| Length | 1450 mm |
| Height | 16 mm |
| Width | 27 mm |
| Product weight | 280.00 g |
Materials & Colors
| Product color | Multicolored |
Application & Mounting
| Replaceable light source | No |
Certificates & Standards
| Standards | CE, UKCA |
PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS
| Quantity of precious metals | 0 mg |
| Quantity of rare earths | 0 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075695092 | BAG 1 |
135 mm x 135 mm x 40 mm | 282.00 g | 0.73 dm³ |
| 4058075695108 | Shipping box 30 |
405 mm x 290 mm x 206 mm | 9019.00 g | 24.19 dm³ |
User instruction / safety instructions
DP HOUSING
DP HOUSING
Legal information
Informationstext 18 Abs 4 ElektroG
Informationstext 18 Abs 4 ElektroG
Declarations of conformity
CE Declaration of Conformity DP HOUSING TH-KIT
CE Declaration of Conformity DP HOUSING TH-KIT
Product line drawing with letters
DP 1500 1xLAMP HOUSING TH-KIT 5x2.5
DP 1500 1xLAMP HOUSING TH-KIT 5x2.5
Product line drawing with numbers
DP 1500 1xLAMP HOUSING TH-KIT 5x2.5
DP 1500 1xLAMP HOUSING TH-KIT 5x2.5
Product line drawing - technical
DP 1500 1xLAMP HOUSING TH-KIT 5x2.5
DP 1500 1xLAMP HOUSING TH-KIT 5x2.5
Catalog info 1
DP 1500 1xLAMP HOUSING TH-KIT 5x2.5
DP 1500 1xLAMP HOUSING TH-KIT 5x2.5
Tender documents
DAMP PROOF HOUSING ACCESSORIES 1500 1xLAMP TH-KIT 5x2.5-EN
DAMP PROOF HOUSING ACCESSORIES 1500 1xLAMP TH-KIT 5x2.5-EN
| EAN | SEG number | STK number | EFO number | ELDAS number |
|---|---|---|---|---|
| 4058075695092 | 7218241 | 4324782 | 3310224 | 941964530 |
