OPTOTRONIC Cable Clamp

OT CABLE CLAMP F-STYLE

GTIN: 4052899325555 Unpacked / 1 Show all packages
Download data sheet
Contact sales
Our warranty conditions

PRODUCT DETAILS

Product benefits
  • Simple and quick cable mounting
  • Sufficient space for cable connection
  • Cost-effective and space-saving solution (TL version)
  • Free cable connection thanks to open flaps
  • Immediate installation thanks to pre-assembled cable clamps
Areas of application
  • Downlights, flat luminaires
  • Suitable for different cable types
  • Suitable for indoor installations
Product features
  • Easy to install and flexible cable clamps
  • Separate cable clamps for primary and secondary side
  • Pre-fixed, captive screws
  • Through-looping (TL version)
Dimensions & Weight
Length 38 mm
Width 53.0 mm
Height 30.0 mm
Product weight 16.00 g
Temperatures & operating conditions
Max.housing temperature in case of fault 110 °C
Permitted rel. humidity during operation 5…85 % 1)
1) Maximum 56 days/year at 85 %
Certificates & Standards
Type of protection IP20
LOGISTICAL DATA
Temperature range at storage -40…+85 °C
PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS
Quantity of precious metals 0 mg
Quantity of rare earths 0 mg
Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage No
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4052899325555 Unpacked
1		 16.00 g
4052899325562 Shipping box
20		 278 mm x 87 mm x 70 mm 383.00 g 1.69 dm³
PRODUCT DATASHEET
637617_Preliminary DS OT CABLE CLAMP F-STYLE (GB)
PDF (282.77 KB)
Product image: white background, diagonal
